Pin Header – QOT

Pin Header – QOT

SKU: QOT Categories: , Tags: ,

Pin Header Dual Row 1.27mm – Pin Header

Application & Features

Public Traffic Lights and Safety
Automation Systems
Electrical Devices
Exercise Equipment
High Reliability
Industrial Controller Boards

Specifications

Flame Rating: UL 94V-0
Current Rating: 1 Amp
Insulator Resistance: 5000 Megohms min
Dielectric Withstanding: AC 500V
Operating Temperature: -40° ~ +105° C
Max Processing Temp: 230° for 30 seconds (260° for 10 seconds)
Contact Material: Brass
Insulator Material: Polyester – Nylon 6T
Finish: Tin, Gold or Duplex Plating

Options

Green Options: High Temp RoHS Compliant
Pin Length : Other Lengths Available
Insulator Spacer Height: Other Hieghts Avail.
Contact Plating: Tin, Duplex Tin/Gold, Gold
Mount Type: Right Angle
Color: Black

Technical Sheets

Download Right Angle PDF
Download Right Angle CAD
